130hp 4WD big tractor farm machinery
  • >= 1  Set US $27,000.000

Big Wheeled Tractor

ISO,CE

EPA4

Farm Tractor

4WD

Gas/Diesel

Qingdao

5 Set /Week

L/C,T/T

Quantity:
Set

Send Enquiry Add To Cart
Product Details

Product Description



Main Features:


1. Chinese highly cost-efficient in-line diesel engines with high fuel efficiency, low maintenance cost, standard preheater and excellent cold start


2. Center console with simple structure, high cost efficiency and easy maintenance


3. 8F+2R gearbox with easy operation and convenient maintenance


4. Optional single/double-acting clutches for different needs and operation


5. Farm land tires, turf tires, construction tires and many other tires to meet needs of different working conditions






Parameters




Model

1304

ENGINE


Rated speed (rpm)

2300

Max torque (N·m/rpm)

500/1500-1720

Rated power (hp)

130

Displacement (L)

7.7

No. of cylinders and Type

6 cylinder, inline, direct injection

Rated fuel consumption (g/kW·h)

≤220

Fuel tank capacity (Ltr)

230

PTO


Max PTO power (Hp)

81.7

PTO speed Std (Opt)

540/1000, 6tooth

POWER TRAIN


Basic trans Std

12F/4R

Max. traction force (k·N)

≥32.0

HYDRAULICS


Delivery (Lpm) hydraulic pump

46

Steering pump

16

Lift capacity at ball end (Kg)

≥2290(22.9kN)

DIMENSIONS & WEIGHT


Length *Width*Height (mm)

5150*2285*3190(cabin)

Wheel base (mm)

2688.5

Wheel tread F (mm)

1822~2153

Wheel tread R (mm)

1662~2262

Min.Ground clearance (mm)

475

Min. operation weight (Kg)

4910(cabin)

Tire size (F/R) (Ag)

14.9-26/18.4-38



Company Information



Henan Dahai Machinery Equipment Co., Ltd is located in Gongyi City, Zhengzhou, Henan, China. And we are established in 2000, covers an area of more than 30 acres, and has more than 100 employees and scientific and technical personnel, including 4 middles and senior scientific research personnel and 8 senior engineers.The factory has more than 30 independent intellectual properties rightspatents, and has developed and produced more than 20 kinds of products to occupy the market. It is a high-tech enterprise integrating scientific research, development, production and sales.The company always adheres to the "quality first, quality service, customer satisfaction, abide by the contract", and its product quality is certified by the higher authorities every year.






Certifications












Packaging & Shipping


1. 2 sets can be loading in a full 20 feet container


2. 4 sets need a full 40 feet container which can  be drive into container directly


3.We also can packaging  it according to your needs


Port: Qingdao


Deliver time: Delivery within 15 days after the payment of deposit








Our Services



Pre-Sales Service

1. Inquiry and consulting support. Sample testing support.

2. Sample testing support.

3. View our company


-Sale service

1. Instance guidance is available on the phone or email any time.

2. we will send technician to the mine site to guide the installation, trial run test, and training operators until the plant works normally.


After-Sales Service

1. Training how to install the machine, training how to use the machine.

2. Engineers available to service machinery overseas.

3. Equipment warranty is 12 months, Equipment spares will be offered with manufacturing cost in at least 10 years since the order is placed.
