100HP small wheel tractors for sale

Big Wheeled Tractor

ISO,CE

EPA4

Farm Tractor

4WD

Gas/Diesel

0 /0

L/C

Quantity:

Send Enquiry
Product Details

Main Features

    1.Adopting Dong fang hong famous diesel engine,good reliability,large torque reserve,low fuel consumption, high economic benefits;

    2.Operate independently double clutch ,high transfer ability,reliable effect,operation more comfortable;

    3.Gear box use 4X(4+2),16 forward gears,8 reverse gears, gear are reasonable,high working efficiency;

4.Adopt independent power output device,steady transmission,large bearing capacity;

    5.Using independent oil hydraulic steering system operation,flexible operation,reliable energy saving;

    6.Using disc brakes,large braking torque,good braking effecting;

    7.Using forced type lifter, reliable use, convenient maintenance;

    8.Final drive adopts planetary reduction structure,compact structure, large reduction ratio;

    9.New streamlined appearance, greaceful ,HY,fashion;



Main technical parameters

model

LT1004

type

4X4

Overall dimension(mm)

Length

4396

Width

2038

High

2810

wheelbase(mm)

2195

Front wheel tread(mm)

1610

Rear wheel tread(mm)

1620-2020

Min.turning radius(m)

One side brake

4.2±0.3

One side not brake

4.9±0.3

Min.using mass

4090

Gear box

F16/R8

Speed(km/h)

going

1.58-33.69

retread

2.41-34.67

Engine

model

LR4M3Z-23

Rated power(kw)

73.5

Rated speed(r/min)

2300

Tyre type

Front tyre

11.2-24

Rear tyre

16.9-34

Steering system type

All hydraulic front wheel steering

Max.lift-off weight(KN)

17.7

PTO type

Rear-mounted semi-detached

PTO speed(r/min)

760/1000(540/1000 or 540/760 or 760/850 is also available)

PTO power(kw)

62.5

Roots in control mode

Height adjustment,floating control

Max.traction(KN)

23.2

Counterweight quality(kg)

front

270

rear

470
